I recently wrote a blog to show how to configure Veeam RMAN plug-in to take database backups. As all DBA knows, configuring a backup, will not go without testing a restore. In this blog I will show how I tested my previous Veeam configuration and backups performed with this Veeam RMAN plug-in on the same ODA. In order to test that the Veeam backups are usable, we will create a new CVEEAMT container database on the ODA and restore existing CDB1 container database into CVEEAMT using a previous existing VEEAM backup we took after configuring the plug-in. The restore will be done through a duplicate.
Pay attention
As we will restore an existing production container database, named CDB1, hosting a PDB named, PDB1, into new CVEEAMT container database, we will have a duplicate PDB. As we know that each PDB is registered into the listener, both PDB1 will be reachable through the same service, which, if the PDB1 is in use, could have dramatical consequence. There before doing the restore into the new container database we will change the domain of the newly created one.
Create new container database CVEEAMT
With odacli we will create the new container databasse named CVEEAMT.
[root@ODA2 ~]# odacli list-dbhomes
ID Name DB Version DB Edition Home Location Status
---------------------------------------- -------------------- -------------------- ---------- -------------------------------------------------------- ----------
3941f574-77bd-4f9e-a1f6-db2bb654f334 OraDB19000_home1 19.25.0.0.241015 SE /u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1 CONFIGURED
b922980f-cecd-4bf8-a688-eb41dd4b5b4b OraDB19000_home2 19.25.0.0.241015 SE /u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_2 CONFIGURED
[root@ODA2 ~]# odacli create-database -dh 3941f574-77bd-4f9e-a1f6-db2bb654f334 -n CVEEAMT -u CVEEAMT_SITE1 -cl OLTP -c -p VEEAMT -no-co -cs AL32UTF8 -ns UTF8 -l AMERICAN -dt AMERICA -s odb1 -r ACFS
Enter SYS, SYSTEM and PDB Admin user password:
Retype SYS, SYSTEM and PDB Admin user password:
Job details
----------------------------------------------------------------
ID: 7d99e795-31e8-4c96-af15-376405180978
Description: Database service creation with DB name: CVEEAMT
Status: Created
Created: February 19, 2025 11:37:16 CET
Message:
Task Name Start Time End Time Status
---------------------------------------- ---------------------------------------- ---------------------------------------- ----------------
[root@ODA2 ~]# odacli describe-job -i 7d99e795-31e8-4c96-af15-376405180978
Job details
----------------------------------------------------------------
ID: 7d99e795-31e8-4c96-af15-376405180978
Description: Database service creation with DB name: CVEEAMT
Status: Success
Created: February 19, 2025 11:37:16 CET
Message:
Task Name Start Time End Time Status
---------------------------------------- ---------------------------------------- ---------------------------------------- ----------------
Setting up SSH equivalence February 19, 2025 11:37:20 CET February 19, 2025 11:37:20 CET Success
Setting up SSH equivalence February 19, 2025 11:37:20 CET February 19, 2025 11:37:20 CET Success
Creating volume datCVEEAMT February 19, 2025 11:37:20 CET February 19, 2025 11:37:35 CET Success
Creating volume rdoCVEEAMT February 19, 2025 11:37:35 CET February 19, 2025 11:37:50 CET Success
Creating ACFS filesystem for DATA February 19, 2025 11:37:50 CET February 19, 2025 11:38:14 CET Success
Creating ACFS filesystem for RECO February 19, 2025 11:38:14 CET February 19, 2025 11:38:37 CET Success
Database Service creation February 19, 2025 11:38:38 CET February 19, 2025 11:52:54 CET Success
Database Creation by RHP February 19, 2025 11:38:38 CET February 19, 2025 11:50:16 CET Success
Change permission for xdb wallet files February 19, 2025 11:50:16 CET February 19, 2025 11:50:17 CET Success
Add Startup Trigger to Open all PDBS February 19, 2025 11:50:17 CET February 19, 2025 11:50:18 CET Success
Place SnapshotCtrlFile in sharedLoc February 19, 2025 11:50:18 CET February 19, 2025 11:50:21 CET Success
SqlPatch upgrade February 19, 2025 11:51:35 CET February 19, 2025 11:51:55 CET Success
Running dbms_stats init_package February 19, 2025 11:51:55 CET February 19, 2025 11:51:56 CET Success
Set log_archive_dest for Database February 19, 2025 11:51:56 CET February 19, 2025 11:51:58 CET Success
Updating the Database version February 19, 2025 11:51:58 CET February 19, 2025 11:52:02 CET Success
Create Users tablespace February 19, 2025 11:52:54 CET February 19, 2025 11:52:57 CET Success
Clear all listeners from Database February 19, 2025 11:52:57 CET February 19, 2025 11:52:58 CET Success
Copy Pwfile to Shared Storage February 19, 2025 11:53:00 CET February 19, 2025 11:53:01 CET Success
[root@ODA2 ~]#
Change the domain
As explained previously, for the newly created container database, we will change the existing domain domain.ch to test.ch, in order not to conflict connecting to both PDB1 once the restore is done.
Existing listener registration for the new CVEEAMT container database and PDB:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] lsnrctl status | grep -i veeam Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CVEEAMTXDB.domain.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CVEEAMT_SITE1.domain.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "veeamt.domain.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service...
As we can see new CDB and new PDB are registered into the listener using existing ODA domain domain.ch.
Let’s change it to test.ch.
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] sqh SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 11:59:25 2025 Version 19.25.0.0.0 Copyright (c) 1982, 2024, Oracle. All rights reserved. Connected to: Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production Version 19.25.0.0.0 SQL> show parameter domain NAME TYPE VALUE ------------------------------------ ----------- ------------------------------ db_domain string domain.ch SQL> alter system set db_domain='test.ch' scope=spfile; System altered.
We will restart the database for the changes to take effects.
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] srvctl stop database -d CVEEAMT_SITE1 oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] srvctl start database -d CVEEAMT_SITE1
We will check listener registration:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] lsnrctl status | grep -i veeam Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CVEEAMTXDB.test.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CVEEAMT_SITE1.test.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "veeamt.test.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service...
As well as domain instance parameter:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] sqh SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 12:02:23 2025 Version 19.25.0.0.0 Copyright (c) 1982, 2024, Oracle. All rights reserved. Connected to: Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production Version 19.25.0.0.0 SQL> show parameter db_domain NAME TYPE VALUE ------------------------------------ ----------- ------------------------------ db_domain string test.ch
Listener configuration
As we will duplicate CDB1 to CVEEAMT, the database name will be renamed. This implies a database restart, which will be done through a listener connection. Therefore, for RMAN to connect to a closed database remotely, we will need to add a static entry that will be used for RMAN duplicate auxiliary connection.
Static registration:
SID_LIST_LISTENER =
(SID_LIST =
(SID_DESC =
(GLOBAL_DBNAME = CVEEAMT_SITE1.test.ch)
(ORACLE_HOME = /u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1)
(SID_NAME = CVEEAMT)
)
)
Backup existing listener configuration on the ODA:
grid@ODA2:~/ [rdbms1900] grinf19 grid@ODA2:~/ [grinf19] cdt grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19] ls -ltrh total 28K -rw-r--r-- 1 grid oinstall 1.5K Feb 14 2018 shrept.lst drwxr-xr-x 2 grid oinstall 4.0K Apr 17 2019 samples -rw-r--r-- 1 grid oinstall 266 Dec 3 17:33 listener.ora.bak.ODA2.grid -rw-r--r-- 1 grid oinstall 504 Dec 3 17:34 listener.ora -rw-r----- 1 grid oinstall 504 Dec 3 17:34 listener2412035PM3433.bak -rw-r----- 1 grid oinstall 179 Dec 3 17:34 sqlnet.ora.20250204 -rw-r----- 1 grid oinstall 200 Feb 4 15:00 sqlnet.ora grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19] mkdir history grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19] cp -p listener.ora ./history/listener.ora.202502191205
Add listener static entry:
grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19] vi listener.ora grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19] diff listener.ora ./history/listener.ora.202502191205 7,15d6 < < SID_LIST_LISTENER = < (SID_LIST = < (SID_DESC = < (GLOBAL_DBNAME = CVEEAMT_SITE1.test.ch) < (ORACLE_HOME = /u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1) < (SID_NAME = CVEEAMT) < ) < ) grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19]
Reload the listener:
grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19] lsnrctl reload LSNRCTL for Linux: Version 19.0.0.0.0 - Production on 19-FEB-2025 13:01:10 Copyright (c) 1991, 2024, Oracle. All rights reserved. Connecting to (DESCRIPTION=(ADDRESS=(PROTOCOL=IPC)(KEY=LISTENER))) The command completed successfully
And check running static registration, that we can recognize with the UNKNOWN status:
grid@ODA2:/u01/app/19.25.0.0/grid/network/admin/ [grinf19] lsnrctl status | grep -i veeam Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CVEEAMTXDB.test.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CVEEAMT_SITE1.test.ch" has 2 instance(s). Instance "CVEEAMT", status UNKNOWN, has 1 handler(s) for this service... Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "veeamt.test.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service...
Configure Oracle network connections
We will configure appropriate tnsnames.ora entries that will be used to connect to target and auxiliary database.
We just need to add new auxiliary entry. The target entry for CDB1 connection is still existing and will permit connection to existing CDB1 production container database.
tnsnames connection to add:
CVEEAMT_SITE1 =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST = ODA2)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SERVICE_NAME = CVEEAMT_SITE1.test.ch)
)
)
tnsnames.ora backup and configuration changes. Entry for CVEEAMT_SITE1 already exist and was performed initially by odacli:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] cdt
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/network/admin/ [CVEEAMT (CDB$ROOT)] ls -ltrh
total 112K
-rw-r--r-- 1 oracle oinstall 1.5K Feb 14 2018 shrept.lst
drwxr-xr-x 2 oracle oinstall 20K Apr 17 2019 samples
drwxr-xr-x 2 oracle oinstall 20K Dec 18 14:01 history
-rw-r----- 1 oracle oinstall 2.6K Feb 19 11:45 tnsnames.ora
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/network/admin/ [CVEEAMT (CDB$ROOT)] cp -p tnsnames.ora ./history/tnsnames.ora.202502191305
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/network/admin/ [CVEEAMT (CDB$ROOT)] vi tnsnames.ora
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/network/admin/ [CVEEAMT (CDB$ROOT)] diff tnsnames.ora ./history/tnsnames.ora.202502191305
115c115
(SERVICE_NAME = CVEEAMT_SITE1.domain.ch)
Test target and auxiliary connections
Test connection to auxiliary database, CVEEAMT:
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/network/admin/ [CVEEAMT (CDB$ROOT)] sqlplus sys@CVEEAMT_SITE1 as sysdba SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 13:07:24 2025 Version 19.25.0.0.0 Copyright (c) 1982, 2024, Oracle. All rights reserved. Enter password: Connected to: Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production Version 19.25.0.0.0 SQL> set line 300 SQL> select instance_name, host_name from v$instance; INSTANCE_NAME HOST_NAME ---------------- ---------------------------------------------------------------- CVEEAMT ODA2.domain.ch SQL>
Test connection to target database, CDB1:
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/network/admin/ [CVEEAMT (CDB$ROOT)] sqlplus sys@CDB1_SITE1 as sysdba SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 13:08:53 2025 Version 19.25.0.0.0 Copyright (c) 1982, 2024, Oracle. All rights reserved. Enter password: Connected to: Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production Version 19.25.0.0.0 SQL> set line 300 SQL> select instance_name, host_name from v$instance; INSTANCE_NAME HOST_NAME ---------------- ---------------------------------------------------------------- CDB1 ODA2.domain.ch SQL>
Delete CVEEAMT DB files
We will now delete CVEEAMT database files before executing the restore.
We will first check spfile:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] cdh oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/ [CVEEAMT (CDB$ROOT)] cd dbs oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] ls -ltrh *CVEEAMT* -rw-r----- 1 oracle asmadmin 24 Feb 19 11:39 lkCVEEAMT_SITE1 -rw-r----- 1 oracle asmadmin 24 Feb 19 11:40 lkCVEEAMT -rw-r----- 1 oracle oinstall 69 Feb 19 11:48 initCVEEAMT.ora -rw-rw---- 1 oracle asmadmin 1.6K Feb 19 12:01 hc_CVEEAMT.dat oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] cat initCVEEAMT.ora SPFILE='/u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/spfileCVEEAMT.ora' oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] srvctl config database -d CVEEAMT_SITE1 | grep -i spfile Spfile: /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/spfileCVEEAMT.ora oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)]
We will stop the database:
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] srvctl stop database -d CVEEAMT_SITE1 oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] CVEEAMT ************************** INSTANCE_NAME : CVEEAMT STATUS : DOWN ************************** Statustime: 2025-02-19 13:11:56
We will backup the spfile:
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] cp -p /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/spfileCVEEAMT.ora /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/spfileCVEEAMT.ora.bak.202502191312 oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] ls -ltrh /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/ total 20K -rw-r----- 1 oracle asmadmin 2.0K Feb 19 11:41 orapwCVEEAMT -rw-r----- 1 oracle oinstall 6.5K Feb 19 12:02 spfileCVEEAMT.ora.bak.202502191312 -rw-r----- 1 oracle asmadmin 6.5K Feb 19 12:02 spfileCVEEAMT.ora oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)]
We will drop CVEEAMT database:
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] sqh SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 13:14:09 2025 Version 19.25.0.0.0 Copyright (c) 1982, 2024, Oracle. All rights reserved. Connected to an idle instance. SQL> startup mount restrict ORACLE instance started. Total System Global Area 4294965864 bytes Fixed Size 9185896 bytes Variable Size 855638016 bytes Database Buffers 3388997632 bytes Redo Buffers 41144320 bytes Database mounted. SQL> drop database; Database dropped. Disconnected from Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production Version 19.25.0.0.0 SQL>
We will restore the spfile that was deleted with the drop database command:
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] ls -ltrh /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/ total 12K -rw-r----- 1 oracle asmadmin 2.0K Feb 19 11:41 orapwCVEEAMT -rw-r----- 1 oracle oinstall 6.5K Feb 19 12:02 spfileCVEEAMT.ora.bak.202502191312 oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] cp -p /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/spfileCVEEAMT.ora.bak.202502191312 /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/spfileCVEEAMT.ora oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] ls -ltrh /u02/app/oracle/oradata/CVEEAMT_SITE1/dbs/ total 20K -rw-r----- 1 oracle asmadmin 2.0K Feb 19 11:41 orapwCVEEAMT -rw-r----- 1 oracle oinstall 6.5K Feb 19 12:02 spfileCVEEAMT.ora.bak.202502191312 -rw-r----- 1 oracle oinstall 6.5K Feb 19 12:02 spfileCVEEAMT.ora
Startup nomount auxiliary database
We will startup in nomount status the auxiliary database, CVEEAMT.
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] sqh SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 13:15:45 2025 Version 19.25.0.0.0 Copyright (c) 1982, 2024, Oracle. All rights reserved. Connected to an idle instance. SQL> startup nomount ORACLE instance started. Total System Global Area 4294965864 bytes Fixed Size 9185896 bytes Variable Size 855638016 bytes Database Buffers 3388997632 bytes Redo Buffers 41144320 bytes SQL>
Database is started in nomunt and static registration available:
oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)] lsnrctl status | grep -i veeam Service "CVEEAMT_SITE1.test.ch" has 2 instance(s). Instance "CVEEAMT", status UNKNOWN, has 1 handler(s) for this service... Instance "CVEEAMT", status BLOCKED, has 1 handler(s) for this service... oracle@ODA2:/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1/dbs/ [CVEEAMT (CDB$ROOT)]
Check CDB1 backups
We will check that last automatic backups that we configured in the crontab at the end of the VEEAM RMAN plug-in configuration are successfully.
INC0 backup:
oracle@ODA2:/u01/app/odaorabase/oracle/admin/CDB1_SITE1/log/ [CDB1 (CDB$ROOT)] ls -ltrh *inc0* | tail -n1 -rw-r--r-- 1 oracle oinstall 17K Feb 16 18:20 CDB1_bck_inc0_no_arc_del_tape_20250216_180002.log oracle@ODA2:/u01/app/odaorabase/oracle/admin/CDB1_SITE1/log/ [CDB1 (CDB$ROOT)] tail CDB1_bck_inc0_no_arc_del_tape_20250216_180002.log Recovery Manager complete. RMAN return Code: 0 #**************************************************************************************************# # END OF: CDB1_bck_inc0_no_arc_del_tape_20250216_180002.log # #--------------------------------------------------------------------------------------------------# # timestamp: 2025-02-16_18:20:54 # #**************************************************************************************************#
INC1 backup:
oracle@ODA2:/u01/app/odaorabase/oracle/admin/CDB1_SITE1/log/ [CDB1 (CDB$ROOT)] ls -ltrh *inc1* | tail -n1 -rw-r--r-- 1 oracle oinstall 17K Feb 18 18:01 CDB1_bck_inc1_no_arc_del_tape_20250218_180002.log oracle@ODA2:/u01/app/odaorabase/oracle/admin/CDB1_SITE1/log/ [CDB1 (CDB$ROOT)] tail CDB1_bck_inc1_no_arc_del_tape_20250218_180002.log Recovery Manager complete. RMAN return Code: 0 #**************************************************************************************************# # END OF: CDB1_bck_inc1_no_arc_del_tape_20250218_180002.log # #--------------------------------------------------------------------------------------------------# # timestamp: 2025-02-18_18:01:31 # #**************************************************************************************************#
Archived log backup:
oracle@ODA2:/u01/app/odaorabase/oracle/admin/CDB1_SITE1/log/ [CDB1 (CDB$ROOT)] ls -ltrh *arc_no_arc* | tail -n1 -rw-r--r-- 1 oracle oinstall 7.6K Feb 19 12:40 CDB1_bck_arc_no_arc_del_tape_20250219_124002.log oracle@ODA2:/u01/app/odaorabase/oracle/admin/CDB1_SITE1/log/ [CDB1 (CDB$ROOT)] tail CDB1_bck_arc_no_arc_del_tape_20250219_124002.log Recovery Manager complete. RMAN return Code: 0 #**************************************************************************************************# # END OF: CDB1_bck_arc_no_arc_del_tape_20250219_124002.log # #--------------------------------------------------------------------------------------------------# # timestamp: 2025-02-19_12:40:49 # #**************************************************************************************************#
Create a new table on PDB1 existing in target CDB1
In order to check some data contents after the restore we will create a TEST1 table in the PDB1 from existing target CDB1 container database.
oracle@ODA2:~/ [CDB1 (CDB$ROOT)] sqh
SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 14:07:35 2025
Version 19.25.0.0.0
Copyright (c) 1982, 2024, Oracle. All rights reserved.
Connected to:
Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production
Version 19.25.0.0.0
SQL> show pdbs
CON_ID CON_NAME OPEN MODE RESTRICTED
---------- ------------------------------ ---------- ----------
2 PDB$SEED READ ONLY NO
3 PDB1 READ WRITE NO
SQL> alter session set container=PDB1;
Session altered.
SQL> create table TEST1 as select * from dba_users;
Table created.
Archived log backup on CDB1
Let’s take a last archived log backup to record last transaction, including our TEST1 table creation.
oracle@ODA2:~/ [CDB1 (CDB$ROOT)] /u01/app/oracle/local/dmk_ha/bin/check_primary.ksh CDB1 "/u01/app/oracle/local/dmk_dbbackup/bin/dmk_rman.ksh -s CDB1 -t bck_arc_no_arc_del_tape.rcv -c /u01/app/odaorabase/oracle/admin/CDB1_SITE1/etc/rman.cfg" 2025-02-19_14:09:49::check_primary.ksh::SetOraEnv ::INFO ==> Environment: CDB1 (/u01/app/odaorahome/oracle/product/19.0.0.0/dbhome_1) 2025-02-19_14:09:49::check_primary.ksh::MainProgram ::INFO ==> Getting V$DATABASE.DB_ROLE for CDB1 2025-02-19_14:09:49::check_primary.ksh::MainProgram ::INFO ==> CDB1 Database Role is: PRIMARY 2025-02-19_14:09:49::check_primary.ksh::MainProgram ::INFO ==> Program going ahead and starting requested command 2025-02-19_14:09:49::check_primary.ksh::MainProgram ::INFO ==> Script : /u01/app/oracle/local/dmk_dbbackup/bin/dmk_rman.ksh -s CDB1 -t bck_arc_no_arc_del_tape.rcv -c /u01/app/odaorabase/oracle/admin/CDB1_SITE1/etc/rman.cfg [OK]::EBL::RMAN::dmk_dbbackup::CDB1::bck_arc_no_arc_del_tape.rcv::RMAN_retCode::0 Logfile is : /u01/app/odaorabase/oracle/admin/CDB1_SITE1/log/CDB1_bck_arc_no_arc_del_tape_20250219_140949.log 2025-02-19_14:10:37::check_primary.ksh::CleanExit ::INFO ==> Program exited with ExitCode : 0 oracle@ODA2:~/ [CDB1 (CDB$ROOT)]
Duplicate CDB1 to CVEEAMT
Let’s do our VEEAM RMAN Plug-in test by restoring CDB1 to CVEEAMT using duplicate from backup command.
The run block will be the following. We will allocate an auxiliary channel using the VEEAM RMAN plug-in library connection that was configured in previous blog.
run {
ALLOCATE AUXILIARY CHANNEL VeeamAgentChannel1 DEVICE TYPE SBT_TAPE PARMS 'SBT_LIBRARY=/opt/veeam/VeeamPluginforOracleRMAN/libOracleRMANPlugin.so' FORMAT 'e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_%I_%d_%T_%U.vab';
duplicate database CDB1 to CVEEAMT;
}
Check auxiliary database files. We can see there is no OMF datafile directory.
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] ls -lrh /u02/app/oracle/oradata/CVEEAMT_SITE1/ total 168K drwx------ 2 root root 64K Feb 19 11:38 lost+found drwxr-x--- 2 oracle oinstall 20K Feb 19 13:15 dbs drwxrwx--- 2 oracle oinstall 20K Feb 19 11:51 arc10 oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)]
Restore the database using the VEEAM backups. We will only use 1 target and 1 auxiliary channel knowing we are running Oracle SE2 edition at customer side:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] rmanh
Recovery Manager: Release 19.0.0.0.0 - Production on Wed Feb 19 14:13:30 2025
Version 19.25.0.0.0
Copyright (c) 1982, 2019, Oracle and/or its affiliates. All rights reserved.
RMAN> connect target sys@CDB1_SITE1
connect target *
target database Password:
connected to target database: CDB1 (DBID=756666048)
RMAN> connect auxiliary sys@CVEEAMT_SITE1
connect auxiliary *
auxiliary database Password:
connected to auxiliary database: CVEEAMT (not mounted)
run {
run {
2> ALLOCATE AUXILIARY CHANNEL VeeamAgentChannel1 DEVICE TYPE SBT_TAPE PARMS 'SBT_LIBRARY=/opt/veeam/VeeamPluginforOracleRMAN/libOracleRMANPlugin.so' FORMAT 'e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_%I_%d_%T_%U.vab';
ALLOCATE AUXILIARY CHANNEL VeeamAgentChannel1 DEVICE TYPE SBT_TAPE PARMS 'SBT_LIBRARY=/opt/veeam/VeeamPluginforOracleRMAN/libOracleRMANPlugin.so' FORMAT 'e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_%I_%d_%T_%U.vab';
3> duplicate database CDB1 to CVEEAMT;
duplicate database CDB1 to CVEEAMT;
4> }
}
using target database control file instead of recovery catalog
allocated channel: VeeamAgentChannel1
channel VeeamAgentChannel1: SID=16 device type=SBT_TAPE
channel VeeamAgentChannel1: Veeam Plug-in for Oracle RMAN
Starting Duplicate Db at 19-FEB-2025 14:15:08
current log archived
duplicating Online logs to Oracle Managed File (OMF) location
duplicating Datafiles to Oracle Managed File (OMF) location
contents of Memory Script:
{
sql clone "alter system set control_files =
''/u04/app/oracle/redo/CVEEAMT/CVEEAMT_SITE1/controlfile/o1_mf_mvcf9nor_.ctl'' comment=
''Set by RMAN'' scope=spfile";
sql clone "alter system set db_name =
''CDB1'' comment=
''Modified by RMAN duplicate'' scope=spfile";
shutdown clone immediate;
startup clone force nomount
restore clone primary controlfile;
alter clone database mount;
}
executing Memory Script
sql statement: alter system set control_files = ''/u04/app/oracle/redo/CVEEAMT/CVEEAMT_SITE1/controlfile/o1_mf_mvcf9nor_.ctl'' comment= ''Set by RMAN'' scope=spfile
sql statement: alter system set db_name = ''CDB1'' comment= ''Modified by RMAN duplicate'' scope=spfile
Oracle instance shut down
Oracle instance started
Total System Global Area 4294965864 bytes
Fixed Size 9185896 bytes
Variable Size 855638016 bytes
Database Buffers 3388997632 bytes
Redo Buffers 41144320 bytes
allocated channel: VeeamAgentChannel1
channel VeeamAgentChannel1: SID=21 device type=SBT_TAPE
channel VeeamAgentChannel1: Veeam Plug-in for Oracle RMAN
Starting restore at 19-FEB-2025 14:15:33
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: restoring control file
channel VeeamAgentChannel1: reading from backup piece c-756666048-20250219-09_RMAN_AUTOBACKUP.vab
channel VeeamAgentChannel1: piece handle=c-756666048-20250219-09_RMAN_AUTOBACKUP.vab tag=TAG20250219T141031
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:07
output file name=/u04/app/oracle/redo/CVEEAMT/CVEEAMT_SITE1/controlfile/o1_mf_mvcf9nor_.ctl
Finished restore at 19-FEB-2025 14:15:56
database mounted
contents of Memory Script:
{
set until scn 13117839;
set newname for clone datafile 1 to new;
set newname for clone datafile 3 to new;
set newname for clone datafile 4 to new;
set newname for clone datafile 5 to new;
set newname for clone datafile 6 to new;
set newname for clone datafile 7 to new;
set newname for clone datafile 8 to new;
set newname for clone datafile 9 to new;
set newname for clone datafile 10 to new;
set newname for clone datafile 11 to new;
set newname for clone datafile 12 to new;
set newname for clone datafile 13 to new;
set newname for clone datafile 14 to new;
set newname for clone datafile 15 to new;
set newname for clone datafile 16 to new;
set newname for clone datafile 17 to new;
set newname for clone datafile 18 to new;
set newname for clone datafile 19 to new;
set newname for clone datafile 20 to new;
set newname for clone datafile 21 to new;
set newname for clone datafile 22 to new;
set newname for clone datafile 23 to new;
set newname for clone datafile 24 to new;
set newname for clone datafile 25 to new;
set newname for clone datafile 26 to new;
set newname for clone datafile 27 to new;
set newname for clone datafile 28 to new;
set newname for clone datafile 29 to new;
set newname for clone datafile 30 to new;
set newname for clone datafile 31 to new;
set newname for clone datafile 32 to new;
set newname for clone datafile 33 to new;
set newname for clone datafile 34 to new;
set newname for clone datafile 35 to new;
set newname for clone datafile 36 to new;
set newname for clone datafile 37 to new;
restore
clone database
;
}
executing Memory Script
executing command: SET until clause
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
Starting restore at 19-FEB-2025 14:16:01
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00005 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_system_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00006 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_sysaux_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00007 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_undotbs1_%u_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250204_en3guuba_471_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250204_en3guuba_471_1_1.vab tag=INC0_20250204_133948
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00010 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
channel VeeamAgentChannel1: restoring section 1 of 3
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_1_1.vab tag=INC0_20250216_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:07
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00010 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
channel VeeamAgentChannel1: restoring section 2 of 3
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_2_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_2_1.vab tag=INC0_20250216_180002
channel VeeamAgentChannel1: restored backup piece 2
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:07
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00010 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
channel VeeamAgentChannel1: restoring section 3 of 3
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_3_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_3_1.vab tag=INC0_20250216_180002
channel VeeamAgentChannel1: restored backup piece 3
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00013 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statspac_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00014 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00017 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00020 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_inde_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00023 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_main_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00026 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_queue_ta_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00029 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00032 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00035 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_%u_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s83hv262_904_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s83hv262_904_1_1.vab tag=INC0_20250216_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:07
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00008 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_system_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00015 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00018 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_idm_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00021 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00024 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00027 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00030 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_in_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00033 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00036 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_ind_%u_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s93hv2h6_905_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s93hv2h6_905_1_1.vab tag=INC0_20250216_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:07
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00009 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_sysaux_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00011 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_users_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00016 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00019 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00022 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_inde_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00025 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00028 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading__%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00031 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statisti_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00034 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_uam_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00037 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_user_dat_%u_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_sa3hv2pf_906_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_sa3hv2pf_906_1_1.vab tag=INC0_20250216_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:07
channel VeeamAgentChannel1: starting datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
channel VeeamAgentChannel1: restoring datafile 00001 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_system_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00003 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_sysaux_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00004 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_undotbs1_%u_.dbf
channel VeeamAgentChannel1: restoring datafile 00012 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_users_%u_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_sb3hv2pu_907_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_sb3hv2pu_907_1_1.vab tag=INC0_20250216_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:07
Finished restore at 19-FEB-2025 14:16:50
contents of Memory Script:
{
switch clone datafile all;
}
executing Memory Script
datafile 1 switched to datafile copy
input datafile copy RECID=40 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_system_mvcpfwvf_.dbf
datafile 3 switched to datafile copy
input datafile copy RECID=41 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_sysaux_mvcpfwtl_.dbf
datafile 4 switched to datafile copy
input datafile copy RECID=42 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_undotbs1_mvcpfwt0_.dbf
datafile 5 switched to datafile copy
input datafile copy RECID=43 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_system_mvcpdmpq_.dbf
datafile 6 switched to datafile copy
input datafile copy RECID=44 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_sysaux_mvcpdmq3_.dbf
datafile 7 switched to datafile copy
input datafile copy RECID=45 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_undotbs1_mvcpdmqj_.dbf
datafile 8 switched to datafile copy
input datafile copy RECID=46 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_system_mvcpfhf3_.dbf
datafile 9 switched to datafile copy
input datafile copy RECID=47 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_sysaux_mvcpfppo_.dbf
datafile 10 switched to datafile copy
input datafile copy RECID=48 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
datafile 11 switched to datafile copy
input datafile copy RECID=49 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_users_mvcpfpz5_.dbf
datafile 12 switched to datafile copy
input datafile copy RECID=50 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_users_mvcpfwvt_.dbf
datafile 13 switched to datafile copy
input datafile copy RECID=51 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statspac_mvcpf8jp_.dbf
datafile 14 switched to datafile copy
input datafile copy RECID=52 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpf7lt_.dbf
datafile 15 switched to datafile copy
input datafile copy RECID=53 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpfgl2_.dbf
datafile 16 switched to datafile copy
input datafile copy RECID=54 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpfost_.dbf
datafile 17 switched to datafile copy
input datafile copy RECID=55 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpf7m4_.dbf
datafile 18 switched to datafile copy
input datafile copy RECID=56 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_idm_mvcpfgls_.dbf
datafile 19 switched to datafile copy
input datafile copy RECID=57 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_mvcpfotj_.dbf
datafile 20 switched to datafile copy
input datafile copy RECID=58 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_inde_mvcpf7mq_.dbf
datafile 21 switched to datafile copy
input datafile copy RECID=59 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_mvcpfgmd_.dbf
datafile 22 switched to datafile copy
input datafile copy RECID=60 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_inde_mvcpfov5_.dbf
datafile 23 switched to datafile copy
input datafile copy RECID=61 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_main_mvcpf7nb_.dbf
datafile 24 switched to datafile copy
input datafile copy RECID=62 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfgmz_.dbf
datafile 25 switched to datafile copy
input datafile copy RECID=63 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfovr_.dbf
datafile 26 switched to datafile copy
input datafile copy RECID=64 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_queue_ta_mvcpf7nx_.dbf
datafile 27 switched to datafile copy
input datafile copy RECID=65 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading_mvcpfgnp_.dbf
datafile 28 switched to datafile copy
input datafile copy RECID=66 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading__mvcpfowc_.dbf
datafile 29 switched to datafile copy
input datafile copy RECID=67 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_mvcpf7oj_.dbf
datafile 30 switched to datafile copy
input datafile copy RECID=68 STAMP=1193494610 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_in_mvcpfgo9_.dbf
datafile 31 switched to datafile copy
input datafile copy RECID=69 STAMP=1193494611 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statisti_mvcpfowx_.dbf
datafile 32 switched to datafile copy
input datafile copy RECID=70 STAMP=1193494611 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpf7p2_.dbf
datafile 33 switched to datafile copy
input datafile copy RECID=71 STAMP=1193494611 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpfgow_.dbf
datafile 34 switched to datafile copy
input datafile copy RECID=72 STAMP=1193494611 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_uam_mvcpfoxh_.dbf
datafile 35 switched to datafile copy
input datafile copy RECID=73 STAMP=1193494611 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_mvcpf7pp_.dbf
datafile 36 switched to datafile copy
input datafile copy RECID=74 STAMP=1193494611 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_ind_mvcpfgph_.dbf
datafile 37 switched to datafile copy
input datafile copy RECID=75 STAMP=1193494611 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_user_dat_mvcpfoy2_.dbf
contents of Memory Script:
{
set until scn 13117839;
recover
clone database
delete archivelog
;
}
executing Memory Script
executing command: SET until clause
Starting recover at 19-FEB-2025 14:16:51
channel VeeamAgentChannel1: starting incremental datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00010: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
channel VeeamAgentChannel1: restoring section 1 of 3
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_1_1.vab tag=INC1_20250218_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting incremental datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00010: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
channel VeeamAgentChannel1: restoring section 2 of 3
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_2_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_2_1.vab tag=INC1_20250218_180002
channel VeeamAgentChannel1: restored backup piece 2
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting incremental datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00010: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
channel VeeamAgentChannel1: restoring section 3 of 3
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_3_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_3_1.vab tag=INC1_20250218_180002
channel VeeamAgentChannel1: restored backup piece 3
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting incremental datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00013: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statspac_mvcpf8jp_.dbf
destination for restore of datafile 00014: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpf7lt_.dbf
destination for restore of datafile 00017: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpf7m4_.dbf
destination for restore of datafile 00020: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_inde_mvcpf7mq_.dbf
destination for restore of datafile 00023: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_main_mvcpf7nb_.dbf
destination for restore of datafile 00026: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_queue_ta_mvcpf7nx_.dbf
destination for restore of datafile 00029: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_mvcpf7oj_.dbf
destination for restore of datafile 00032: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpf7p2_.dbf
destination for restore of datafile 00035: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_mvcpf7pp_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_uc3i4aqd_972_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_uc3i4aqd_972_1_1.vab tag=INC1_20250218_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting incremental datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00008: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_system_mvcpfhf3_.dbf
destination for restore of datafile 00015: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpfgl2_.dbf
destination for restore of datafile 00018: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_idm_mvcpfgls_.dbf
destination for restore of datafile 00021: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_mvcpfgmd_.dbf
destination for restore of datafile 00024: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfgmz_.dbf
destination for restore of datafile 00027: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading_mvcpfgnp_.dbf
destination for restore of datafile 00030: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_in_mvcpfgo9_.dbf
destination for restore of datafile 00033: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpfgow_.dbf
destination for restore of datafile 00036: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_ind_mvcpfgph_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_ud3i4aqk_973_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_ud3i4aqk_973_1_1.vab tag=INC1_20250218_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting incremental datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00009: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_sysaux_mvcpfppo_.dbf
destination for restore of datafile 00011: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_users_mvcpfpz5_.dbf
destination for restore of datafile 00016: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpfost_.dbf
destination for restore of datafile 00019: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_mvcpfotj_.dbf
destination for restore of datafile 00022: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_inde_mvcpfov5_.dbf
destination for restore of datafile 00025: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfovr_.dbf
destination for restore of datafile 00028: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading__mvcpfowc_.dbf
destination for restore of datafile 00031: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statisti_mvcpfowx_.dbf
destination for restore of datafile 00034: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_uam_mvcpfoxh_.dbf
destination for restore of datafile 00037: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_user_dat_mvcpfoy2_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_ue3i4aqr_974_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_ue3i4aqr_974_1_1.vab tag=INC1_20250218_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
channel VeeamAgentChannel1: starting incremental datafile backup set restore
channel VeeamAgentChannel1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00001: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_system_mvcpfwvf_.dbf
destination for restore of datafile 00003: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_sysaux_mvcpfwtl_.dbf
destination for restore of datafile 00004: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_undotbs1_mvcpfwt0_.dbf
destination for restore of datafile 00012: /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_users_mvcpfwvt_.dbf
channel VeeamAgentChannel1: reading from backup piece e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_uf3i4ar2_975_1_1.vab
channel VeeamAgentChannel1: piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_uf3i4ar2_975_1_1.vab tag=INC1_20250218_180002
channel VeeamAgentChannel1: restored backup piece 1
channel VeeamAgentChannel1: restore complete, elapsed time: 00:00:03
starting media recovery
archived log for thread 1 with sequence 236 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_18/o1_mf_1_236_mv9h6t7z_.arc
archived log for thread 1 with sequence 237 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_18/o1_mf_1_237_mv9rjr7s_.arc
archived log for thread 1 with sequence 238 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_238_mvb6lr1f_.arc
archived log for thread 1 with sequence 239 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_239_mvbnnqvg_.arc
archived log for thread 1 with sequence 240 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_240_mvc2pr6m_.arc
archived log for thread 1 with sequence 241 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_241_mvcjrr7v_.arc
archived log for thread 1 with sequence 242 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_242_mvcp13py_.arc
archived log for thread 1 with sequence 243 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_243_mvcpbw6z_.arc
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_18/o1_mf_1_236_mv9h6t7z_.arc thread=1 sequence=236
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_18/o1_mf_1_237_mv9rjr7s_.arc thread=1 sequence=237
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_238_mvb6lr1f_.arc thread=1 sequence=238
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_239_mvbnnqvg_.arc thread=1 sequence=239
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_240_mvc2pr6m_.arc thread=1 sequence=240
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_241_mvcjrr7v_.arc thread=1 sequence=241
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_242_mvcp13py_.arc thread=1 sequence=242
archived log file name=/u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_19/o1_mf_1_243_mvcpbw6z_.arc thread=1 sequence=243
media recovery complete, elapsed time: 00:00:03
Finished recover at 19-FEB-2025 14:17:17
released channel: VeeamAgentChannel1
Oracle instance started
Total System Global Area 4294965864 bytes
Fixed Size 9185896 bytes
Variable Size 855638016 bytes
Database Buffers 3388997632 bytes
Redo Buffers 41144320 bytes
contents of Memory Script:
{
sql clone "alter system set db_name =
''CVEEAMT'' comment=
''Reset to original value by RMAN'' scope=spfile";
}
executing Memory Script
sql statement: alter system set db_name = ''CVEEAMT'' comment= ''Reset to original value by RMAN'' scope=spfile
Oracle instance started
Total System Global Area 4294965864 bytes
Fixed Size 9185896 bytes
Variable Size 855638016 bytes
Database Buffers 3388997632 bytes
Redo Buffers 41144320 bytes
sql statement: CREATE CONTROLFILE REUSE SET DATABASE "CVEEAMT" RESETLOGS ARCHIVELOG
MAXLOGFILES 16
MAXLOGMEMBERS 3
MAXDATAFILES 1024
MAXINSTANCES 8
MAXLOGHISTORY 292
LOGFILE
GROUP 1 SIZE 512 M ,
GROUP 2 SIZE 512 M ,
GROUP 3 SIZE 512 M
DATAFILE
'/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_system_mvcpfwvf_.dbf',
'/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_system_mvcpdmpq_.dbf',
'/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_system_mvcpfhf3_.dbf'
CHARACTER SET AL32UTF8
contents of Memory Script:
{
set newname for clone tempfile 1 to new;
set newname for clone tempfile 2 to new;
set newname for clone tempfile 3 to new;
switch clone tempfile all;
catalog clone datafilecopy "/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_sysaux_mvcpfwtl_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_undotbs1_mvcpfwt0_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_sysaux_mvcpdmq3_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_undotbs1_mvcpdmqj_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_sysaux_mvcpfppo_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_users_mvcpfpz5_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_users_mvcpfwvt_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statspac_mvcpf8jp_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpf7lt_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpfgl2_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpfost_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpf7m4_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_idm_mvcpfgls_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_mvcpfotj_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_inde_mvcpf7mq_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_mvcpfgmd_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_inde_mvcpfov5_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_main_mvcpf7nb_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfgmz_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfovr_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_queue_ta_mvcpf7nx_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading_mvcpfgnp_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading__mvcpfowc_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_mvcpf7oj_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_in_mvcpfgo9_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statisti_mvcpfowx_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpf7p2_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpfgow_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_uam_mvcpfoxh_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_mvcpf7pp_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_ind_mvcpfgph_.dbf",
"/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_user_dat_mvcpfoy2_.dbf";
switch clone datafile all;
}
executing Memory Script
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
renamed tempfile 1 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_temp_%u_.tmp in control file
renamed tempfile 2 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_temp_%u_.tmp in control file
renamed tempfile 3 to /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temp_%u_.tmp in control file
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_sysaux_mvcpfwtl_.dbf RECID=1 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_undotbs1_mvcpfwt0_.dbf RECID=2 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_sysaux_mvcpdmq3_.dbf RECID=3 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_undotbs1_mvcpdmqj_.dbf RECID=4 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_sysaux_mvcpfppo_.dbf RECID=5 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf RECID=6 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_users_mvcpfpz5_.dbf RECID=7 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_users_mvcpfwvt_.dbf RECID=8 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statspac_mvcpf8jp_.dbf RECID=9 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpf7lt_.dbf RECID=10 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpfgl2_.dbf RECID=11 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpfost_.dbf RECID=12 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpf7m4_.dbf RECID=13 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_idm_mvcpfgls_.dbf RECID=14 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_mvcpfotj_.dbf RECID=15 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_inde_mvcpf7mq_.dbf RECID=16 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_mvcpfgmd_.dbf RECID=17 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_inde_mvcpfov5_.dbf RECID=18 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_main_mvcpf7nb_.dbf RECID=19 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfgmz_.dbf RECID=20 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfovr_.dbf RECID=21 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_queue_ta_mvcpf7nx_.dbf RECID=22 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading_mvcpfgnp_.dbf RECID=23 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading__mvcpfowc_.dbf RECID=24 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_mvcpf7oj_.dbf RECID=25 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_in_mvcpfgo9_.dbf RECID=26 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statisti_mvcpfowx_.dbf RECID=27 STAMP=1193494661
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpf7p2_.dbf RECID=28 STAMP=1193494662
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpfgow_.dbf RECID=29 STAMP=1193494662
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_uam_mvcpfoxh_.dbf RECID=30 STAMP=1193494662
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_mvcpf7pp_.dbf RECID=31 STAMP=1193494662
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_ind_mvcpfgph_.dbf RECID=32 STAMP=1193494662
cataloged datafile copy
datafile copy file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_user_dat_mvcpfoy2_.dbf RECID=33 STAMP=1193494662
datafile 3 switched to datafile copy
input datafile copy RECID=1 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_sysaux_mvcpfwtl_.dbf
datafile 4 switched to datafile copy
input datafile copy RECID=2 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_undotbs1_mvcpfwt0_.dbf
datafile 6 switched to datafile copy
input datafile copy RECID=3 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_sysaux_mvcpdmq3_.dbf
datafile 7 switched to datafile copy
input datafile copy RECID=4 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987BF93B6232B35E063425C210AC02A/datafile/o1_mf_undotbs1_mvcpdmqj_.dbf
datafile 9 switched to datafile copy
input datafile copy RECID=5 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_sysaux_mvcpfppo_.dbf
datafile 10 switched to datafile copy
input datafile copy RECID=6 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
datafile 11 switched to datafile copy
input datafile copy RECID=7 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_users_mvcpfpz5_.dbf
datafile 12 switched to datafile copy
input datafile copy RECID=8 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_users_mvcpfwvt_.dbf
datafile 13 switched to datafile copy
input datafile copy RECID=9 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statspac_mvcpf8jp_.dbf
datafile 14 switched to datafile copy
input datafile copy RECID=10 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpf7lt_.dbf
datafile 15 switched to datafile copy
input datafile copy RECID=11 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_ami_hub__mvcpfgl2_.dbf
datafile 16 switched to datafile copy
input datafile copy RECID=12 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpfost_.dbf
datafile 17 switched to datafile copy
input datafile copy RECID=13 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_base_sys_mvcpf7m4_.dbf
datafile 18 switched to datafile copy
input datafile copy RECID=14 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_idm_mvcpfgls_.dbf
datafile 19 switched to datafile copy
input datafile copy RECID=15 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_mvcpfotj_.dbf
datafile 20 switched to datafile copy
input datafile copy RECID=16 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_inde_mvcpf7mq_.dbf
datafile 21 switched to datafile copy
input datafile copy RECID=17 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_mvcpfgmd_.dbf
datafile 22 switched to datafile copy
input datafile copy RECID=18 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_inde_mvcpfov5_.dbf
datafile 23 switched to datafile copy
input datafile copy RECID=19 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_main_mvcpf7nb_.dbf
datafile 24 switched to datafile copy
input datafile copy RECID=20 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfgmz_.dbf
datafile 25 switched to datafile copy
input datafile copy RECID=21 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_md_readi_mvcpfovr_.dbf
datafile 26 switched to datafile copy
input datafile copy RECID=22 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_queue_ta_mvcpf7nx_.dbf
datafile 27 switched to datafile copy
input datafile copy RECID=23 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading_mvcpfgnp_.dbf
datafile 28 switched to datafile copy
input datafile copy RECID=24 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_reading__mvcpfowc_.dbf
datafile 29 switched to datafile copy
input datafile copy RECID=25 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_mvcpf7oj_.dbf
datafile 30 switched to datafile copy
input datafile copy RECID=26 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_in_mvcpfgo9_.dbf
datafile 31 switched to datafile copy
input datafile copy RECID=27 STAMP=1193494661 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statisti_mvcpfowx_.dbf
datafile 32 switched to datafile copy
input datafile copy RECID=28 STAMP=1193494662 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpf7p2_.dbf
datafile 33 switched to datafile copy
input datafile copy RECID=29 STAMP=1193494662 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpfgow_.dbf
datafile 34 switched to datafile copy
input datafile copy RECID=30 STAMP=1193494662 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_uam_mvcpfoxh_.dbf
datafile 35 switched to datafile copy
input datafile copy RECID=31 STAMP=1193494662 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_mvcpf7pp_.dbf
datafile 36 switched to datafile copy
input datafile copy RECID=32 STAMP=1193494662 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_unit_ind_mvcpfgph_.dbf
datafile 37 switched to datafile copy
input datafile copy RECID=33 STAMP=1193494662 file name=/u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_user_dat_mvcpfoy2_.dbf
Reenabling controlfile options for auxiliary database
Executing: alter database force logging
contents of Memory Script:
{
Alter clone database open resetlogs;
}
executing Memory Script
database opened
contents of Memory Script:
{
sql clone "alter pluggable database all open";
}
executing Memory Script
sql statement: alter pluggable database all open
Finished Duplicate Db at 19-FEB-2025 14:17:48
We can see that RMAN used INC0 VEEAM backups:
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250204_en3guuba_471_1_1.vab tag=INC0_20250204_133948
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_1_1.vab tag=INC0_20250216_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_2_1.vab tag=INC0_20250216_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s53hv217_901_3_1.vab tag=INC0_20250216_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s83hv262_904_1_1.vab tag=INC0_20250216_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_s93hv2h6_905_1_1.vab tag=INC0_20250216_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_sa3hv2pf_906_1_1.vab tag=INC0_20250216_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250216_sb3hv2pu_907_1_1.vab tag=INC0_20250216_180002We can see that RMAN used INC1 VEEAM backups:
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_1_1.vab tag=INC1_20250218_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_2_1.vab tag=INC1_20250218_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_u93i4ap9_969_3_1.vab tag=INC1_20250218_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_uc3i4aqd_972_1_1.vab tag=INC1_20250218_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_ud3i4aqk_973_1_1.vab tag=INC1_20250218_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_ue3i4aqr_974_1_1.vab tag=INC1_20250218_180002
piece handle=e718bc55-0c60-43bc-b1f7-f8cf2c793120/RMAN_756666048_CDB1_20250218_uf3i4ar2_975_1_1.vab tag=INC1_20250218_180002RMAN duplicate did not used any of the archived log backup as archived log file was still existing in the FRA, which is ok for our tests, see media recovery message like:
archived log for thread 1 with sequence 236 is already on disk as file /u03/app/oracle/fast_recovery_area/CDB1_SITE1/archivelog/2025_02_18/o1_mf_1_236_mv9h6t7z_.arcRMAN duplicated played all archived log files as we did not specified any until_scn or until_time clause.
Checks
We have 2 PDB1 pdb one for each CDB on appropriate domain registered to the listener:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] lsnrctl status | grep -iE veeam\|pdb1 Instance "CDB1", status READY, has 1 handler(s) for this service... Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CDB1XDB.domain.ch" has 1 instance(s). Instance "CDB1", status READY, has 1 handler(s) for this service... Service "CDB1_SITE1.domain.ch" has 1 instance(s). Instance "CDB1", status READY, has 1 handler(s) for this service... Service "CVEEAMTXDB.test.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "CVEEAMT_SITE1.test.ch" has 2 instance(s). Instance "CVEEAMT", status UNKNOWN, has 1 handler(s) for this service... Instance "CVEEAMT", status READY, has 1 handler(s) for this service... Service "PDB1_PRI.domain.ch" has 1 instance(s). Instance "CDB1", status READY, has 1 handler(s) for this service... Service "pdb1.domain.ch" has 1 instance(s). Instance "CDB1", status READY, has 1 handler(s) for this service... Service "pdb1.test.ch" has 1 instance(s). Instance "CVEEAMT", status READY, has 1 handler(s) for this service... oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)]
Check target container database CDB1:
oracle@ODA2:~/ [CDB1 (CDB$ROOT)] sqh
SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 14:46:06 2025
Version 19.25.0.0.0
Copyright (c) 1982, 2024, Oracle. All rights reserved.
Connected to:
Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production
Version 19.25.0.0.0
SQL> show pdbs
CON_ID CON_NAME OPEN MODE RESTRICTED
---------- ------------------------------ ---------- ----------
2 PDB$SEED READ ONLY NO
3 PDB1 READ WRITE NO
SQL> select instance_name from v$instance;
INSTANCE_NAME
----------------
CDB1
SQL> set line 300
SQL> col name for a20
SQL> select NAME, GUID, total_size/1024/1024/1024 GB from v$pdbs;
NAME GUID GB
-------------------- -------------------------------- ----------
PDB$SEED 2987BF93B6232B35E063425C210AC02A 1.09960938
PDB1 2987D4B68CF25579E063425C210AB61B 46.3935547
SQL>
Check auxiliary container database CVEEAMT. We will check PDB1, that our TEST1 table exists, and also database files:
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] CVEEAMT
******************************************************
INSTANCE_NAME : CVEEAMT
DB_NAME : CVEEAMT
DB_UNIQUE_NAME : CVEEAMT_SITE1
STATUS : OPEN READ WRITE
LOG_MODE : ARCHIVELOG
USERS/SESSIONS : Normal: 0/0, Oracle-maintained: 2/7
DATABASE_ROLE : PRIMARY
FLASHBACK_ON : NO
FORCE_LOGGING : YES
VERSION : 19.25.0.0.0
NLS_LANG : AMERICAN_AMERICA.AL32UTF8
CDB_ENABLED : YES
PDBs : PDB1 PDB$SEED
******************************************************
PDB color: pdbname=open read-write, pdbname=open read-only
Statustime: 2025-02-19 14:42:03
oracle@ODA2:~/ [CVEEAMT (CDB$ROOT)] sqh
SQL*Plus: Release 19.0.0.0.0 - Production on Wed Feb 19 14:42:05 2025
Version 19.25.0.0.0
Copyright (c) 1982, 2024, Oracle. All rights reserved.
Connected to:
Oracle Database 19c Standard Edition 2 Release 19.0.0.0.0 - Production
Version 19.25.0.0.0
SQL> show pdbs
CON_ID CON_NAME OPEN MODE RESTRICTED
---------- ------------------------------ ---------- ----------
2 PDB$SEED READ ONLY NO
3 PDB1 READ WRITE NO
SQL> alter session set container=PDB1;
Session altered.
SQL> select count(*) from test1;
COUNT(*)
----------
51
SQL> select instance_name from v$instance;
INSTANCE_NAME
----------------
CVEEAMT
SQL> @qdbstbssize.sql
Container Nb Extent Segment Alloc. Space Max. Percent Block
name Name files Type Mgmnt Mgmnt size (GB) free (GB) size (GB) used % size Log Encrypt Compress
--------------- --------------- ----- ---- ------ ------- ---------- ---------- ---------- ---------- ----- --- ------- --------
PDB1 XXX_XXX_INDEXES 1 DATA LM-SYS AUTO 1.00 .90 10.00 1.00 8 KB YES NO NO
XXX_XXX_TABLES 1 DATA LM-SYS AUTO 1.00 .91 10.00 .95 8 KB YES NO NO
XXXX_SYSTEM 1 DATA LM-SYS AUTO 1.00 .70 10.00 3.01 8 KB YES NO NO
XXXX_SYSTEM_IND 1 DATA LM-SYS AUTO 1.00 .86 10.00 1.36 8 KB YES NO NO
EXES
IDM 1 DATA LM-SYS AUTO 1.00 .85 10.00 1.53 8 KB YES NO NO
JOB 1 DATA LM-SYS AUTO 1.00 .92 10.00 .83 8 KB YES NO NO
JOB_INDEXES 1 DATA LM-SYS AUTO 1.00 .92 10.00 .83 8 KB YES NO NO
LOG 1 DATA LM-SYS AUTO 1.00 .88 10.00 1.24 8 KB YES NO NO
LOG_INDEXES 1 DATA LM-SYS AUTO 1.00 .86 10.00 1.41 8 KB YES NO NO
MAIN 1 DATA LM-SYS AUTO 1.00 .93 10.00 .74 8 KB YES NO NO
XX_XXXXXXX 1 DATA LM-SYS AUTO 1.00 .92 10.00 .78 8 KB YES NO NO
XX_XX_XXXXXXX_INDE 1 DATA LM-SYS AUTO 1.00 .92 10.00 .80 8 KB YES NO NO
XES
QUEUE_TABLES 1 DATA LM-SYS AUTO 1.00 .93 10.00 .75 8 KB YES NO NO
XXXXXXX 1 DATA LM-SYS AUTO 1.00 .84 10.00 1.61 8 KB YES NO NO
XXXXXXX_INDEXES 1 DATA LM-SYS AUTO 1.00 .88 10.00 1.20 8 KB YES NO NO
SETUP 1 DATA LM-SYS AUTO 1.00 .91 10.00 .93 8 KB YES NO NO
SETUP_INDEXES 1 DATA LM-SYS AUTO 1.00 .91 10.00 .88 8 KB YES NO NO
STATISTIC 1 DATA LM-SYS AUTO 1.00 .71 10.00 2.85 8 KB YES NO NO
STATSPACK 1 DATA LM-SYS AUTO .98 .13 2.00 42.32 8 KB YES NO NO
SYSAUX 1 DATA LM-SYS AUTO .58 .04 10.00 5.32 8 KB YES NO NO
SYSTEM 1 DATA LM-SYS MANUAL .62 .05 4.00 14.21 8 KB YES NO NO
TEMP 1 TEMP LM-UNI MANUAL .22 .66 31.00 -1.40 8 KB NO NO NO
TEMPORARY_DATA 1 DATA LM-SYS AUTO 1.00 .93 10.00 .67 8 KB YES NO NO
TEMPORARY_DATA_ 1 DATA LM-SYS AUTO 1.00 .93 10.00 .66 8 KB YES NO NO
INDEXES
XXX 1 DATA LM-SYS AUTO 1.00 .93 10.00 .68 8 KB YES NO NO
UNDOTBS1 1 UNDO LM-SYS MANUAL 20.00 19.97 20.00 .13 8 KB YES NO NO
XXXX 1 DATA LM-SYS AUTO 1.00 .92 10.00 .82 8 KB YES NO NO
XXXX_INDEXES 1 DATA LM-SYS AUTO 1.00 .91 10.00 .94 8 KB YES NO NO
USERS 1 DATA LM-SYS AUTO .00 .00 2.00 .05 8 KB YES NO NO
USER_DATA 1 DATA LM-SYS AUTO 1.00 .93 10.00 .66 8 KB YES NO NO
*************** ----- ---------- ---------- ----------
TOTAL 30 46.39 42.14 309.00
SQL> alter session set container=cdb$root;
Session altered.
SQL> set lines 300
SQL> col name for a20
SQL> select NAME, GUID, total_size/1024/1024/1024 GB from v$pdbs;
NAME GUID GB
-------------------- -------------------------------- ----------
PDB$SEED 2987BF93B6232B35E063425C210AC02A 1.09960938
PDB1 2987D4B68CF25579E063425C210AB61B 46.3935547
2 rows selected.
SQL> set lines 300 pages 500
SQL> col file_name for a150
SQL> select instance_name from v$instance;
INSTANCE_NAME
----------------
CVEEAMT
SQL> show pdbs
CON_ID CON_NAME OPEN MODE RESTRICTED
---------- ------------------------------ ---------- ----------
2 PDB$SEED READ ONLY NO
3 PDB1 READ WRITE NO
SQL> select con_id, file_name from cdb_data_files;
CON_ID FILE_NAME
---------- ------------------------------------------------------------------------------------------------------------------------------------------------------
1 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_system_mvcpfwvf_.dbf
1 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_sysaux_mvcpfwtl_.dbf
1 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_undotbs1_mvcpfwt0_.dbf
1 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/datafile/o1_mf_users_mvcpfwvt_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_system_mvcpfhf3_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_sysaux_mvcpfppo_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_undotbs1_mvcpdoc3_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_users_mvcpfpz5_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statspac_mvcpf8jp_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxx_xxx__mvcpf7lt_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxx_xxx__mvcpfgl2_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxxx_sys_mvcpfost_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxxx_sys_mvcpf7m4_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxx_mvcpfgls_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_mvcpfotj_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_job_inde_mvcpf7mq_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_mvcpfgmd_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_log_inde_mvcpfov5_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxxx_mvcpf7nb_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xx_xxxxx_mvcpfgmz_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xx_xxxxx_mvcpfgmz_mvcpfovr_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_queue_ta_mvcpf7nx_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxxxxxx_mvcpfgnp_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxxxxxx__mvcpfowc_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_mvcpf7oj_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_setup_in_mvcpfgo9_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_statisti_mvcpfowx_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpf7p2_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_temporar_mvcpfgow_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxx_mvcpfoxh_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxxx_mvcpf7pp_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_xxxx_ind_mvcpfgph_.dbf
3 /u02/app/oracle/oradata/CVEEAMT_SITE1/CVEEAMT_SITE1/2987D4B68CF25579E063425C210AB61B/datafile/o1_mf_user_dat_mvcpfoy2_.dbf
33 rows selected.
SQL>
As we can see, the restore from CDB1 into CVEEAMT with RMAN duplicate command using VEEAM backups could be done successfully.
Cleanup
Let’s cleanup by deleting CVEEAMT database.
[root@ODA2 ~]# odacli delete-database -n CVEEAMT
{
"jobId" : "565aa4e3-9152-45f8-a739-dd7c53b22044",
"status" : "Running",
"message" : "",
"reports" : [ {
"taskId" : "TaskDcsJsonRpcExt_14309",
"taskName" : "Validate DB 96122ad1-182a-4059-8a26-677300d93d71 for deletion",
"nodeName" : "ODA2",
"taskResult" : "",
"startTime" : "February 19, 2025 14:55:01 CET",
"endTime" : null,
"duration" : "00:00:00.10",
"status" : "Running",
"taskDescription" : null,
"parentTaskId" : "TaskSequential_14307",
"jobId" : "565aa4e3-9152-45f8-a739-dd7c53b22044",
"tags" : [ ],
"reportLevel" : "Info",
"updatedTime" : "February 19, 2025 14:55:01 CET"
} ],
"createTimestamp" : "February 19, 2025 14:54:59 CET",
"resourceList" : [ ],
"description" : "Database service deletion with DB name: CVEEAMT with ID : 96122ad1-182a-4059-8a26-677300d93d71",
"updatedTime" : "February 19, 2025 14:55:01 CET",
"jobType" : null,
"cpsMetadata" : null
}
[root@ODA2 ~]# odacli describe-job -i "565aa4e3-9152-45f8-a739-dd7c53b22044"
Job details
----------------------------------------------------------------
ID: 565aa4e3-9152-45f8-a739-dd7c53b22044
Description: Database service deletion with DB name: CVEEAMT with ID : 96122ad1-182a-4059-8a26-677300d93d71
Status: Success
Created: February 19, 2025 14:54:59 CET
Message:
Task Name Start Time End Time Status
---------------------------------------- ---------------------------------------- ---------------------------------------- ----------------
Validate DB February 19, 2025 14:55:01 CET February 19, 2025 14:55:01 CET Success
96122ad1-182a-4059-8a26-677300d93d71
for deletion
Deleting the RMAN logs February 19, 2025 14:55:01 CET February 19, 2025 14:55:01 CET Success
Database Deletion By RHP February 19, 2025 14:55:01 CET February 19, 2025 14:56:07 CET Success
Unregister DB From Cluster February 19, 2025 14:56:07 CET February 19, 2025 14:56:08 CET Success
Kill PMON Process February 19, 2025 14:56:08 CET February 19, 2025 14:56:08 CET Success
Database Files Deletion February 19, 2025 14:56:08 CET February 19, 2025 14:56:08 CET Success
Deleting Volume February 19, 2025 14:56:13 CET February 19, 2025 14:56:17 CET Success
Deleting Volume February 19, 2025 14:56:23 CET February 19, 2025 14:56:26 CET Success
We would also restore initial listener.ora configuration file. As you might see, there is job in the appliance that already regularly restore initial listener configuration file.
We would also delete our TEST1 table we created in the production PDB1.
To wrap up…
We could successfully restore CDB1 into CVEEAMT with RMAN duplicate command using VEEAM backups. This validates our VEEAM RMAN plug-in previous configuration and also any backup done with the VEEAM RMAN plug-in.
![Thumbnail [60x60]](https://www.dbi-services.com/blog/wp-content/uploads/2022/08/MAW_web-min-scaled.jpg)
![Thumbnail [90x90]](https://www.dbi-services.com/blog/wp-content/uploads/2022/08/JDU_web-min-scaled.jpg)
![Thumbnail [90x90]](https://www.dbi-services.com/blog/wp-content/uploads/2025/05/JDE_Web-1-scaled.jpg)
![Thumbnail [90x90]](https://www.dbi-services.com/blog/wp-content/uploads/2025/05/martin_bracher_2048x1536.jpg)
![Thumbnail [90x90]](https://www.dbi-services.com/blog/wp-content/uploads/2025/03/OBA_web-scaled.jpg)
